The production line is cooled by water through the gear drive module template,the module is air-cooled and the forming speed is fast.
The molding process is divided into two types: internal pressure blow molding and vacuum molding.
The module has high machining precision, uniform corrugated shape, consistent seams, and smooth inner and outer wals.
The single wall corrugated pipe production line mainly includes single screw extruder,forming machine,dle mold, cooling device,counter, winding machine, and can continuously produce pipes of different pipe diameters.
The production line series are divided into Ф10-Ф40mm,Ф50-Ф110, Ф75-Ф200 (mm).
Advantage
Closed track structure,the module runs stably in the molding machine,running track,high-speed and reliable operation,low waste pipe rate,good pipe forming and beautiful appearance.
The template type string water can be cooled by high-pressure cooling water,which can quickly cool the module,and effectively solve the key problem that the high-speed production pipe can not be cooled down,which affects the pipe production speed.
The molding machine adopts the building block design,which can lengthen the molding machine according to the customer's requirements,so as to increase the length of the forming section and the cooling time,so as to meet the customer's higher speed requirements.
The module adopts advanced five axis cnc machining center,which has high precision and effectively ensures the stability of running track
The safety of the equipment,as well as the use of automatic lubrication device,have been improved
Double station ticket collector,easy to operate,quick to change coil,no impact on pipe production
It can produce single wall bellows,prestressed bellows,profiled joint bellows,etc.
Technical Parameter
